Normalization in Electrocatalysis: Distinguishing Real, and Electrochemically Active Surface Areas
Jon Bjarke Valbaek Mygind a, Marcel J. Rost b, María Escudero-Escribano a c
a Catalan Institute of Nanoscience and Nanotechnology, Campus UAB, Bellaterra, 08193 Barcelona, Spain
b Huygens-Kamerlingh Onnes Laboratory, Leiden University, Niels Bohrweg 2, 2333 CA Leiden, The Netherlands
c Catalan Institution for Research and Advanced Studies (ICREA), Passeig de Lluís Companys, 23, 08010 Barcelona, Spain
Proceedings of MATSUS Spring 2026 Conference (MATSUSSpring26)
E1 Breaking New Bonds: Electrocatalysis for Emerging Transformations
Barcelona, Spain, 2026 March 23rd - 27th
Organizers: María Escudero-Escribano and Ifan Stephens
Oral, Jon Bjarke Valbaek Mygind, presentation 474
Publication date: 15th December 2025

Accurate activity normalization remains a central challenge in electrocatalysis. Current densities are routinely reported per unit surface area. However, this requires a clear distinction between the real surface area (RSA) and the electrochemically active surface area (ECSA). Furthermore, uncertainties in these area determinations propagate directly into the reported current densities, restricting fair comparisons of electrocatalytic activity across studies.

In this contribution, we examine the structure of real electrode surfaces and argue which surface regions should be counted as part of the RSA and which subset contributes to the ECSA. We provide measurement protocols to probe the electrode surface using double-layer capacitance and adsorption-limited faradaic reactions. We show that representative reference values per unit area are required to convert these measurements into quantitative surface areas. Depending on how they are applied, these reference values yield estimates of either RSA or ECSA. As the reference values are condition-dependent, we outline how to construct them to enable consistent and rational current normalization.

Finally, we outline best practices and protocols for current normalization that support rigorous comparison of emerging electrocatalytic transformations central to sustainable fuels and chemicals.
