Low Temperature Synthetic Route to Bi2S3 Powders from Xanthate Precursors Using Melt Reaction for Photovoltaic Applications

Mousa Hossin^a^,^b, Abdulaziz Alanazi^a^,^d, Paul O'Brien^a^,^c, David Lewis^a^,^c

^aSchool of Chemistry, the University of Manchester, Oxford Road, Manchester, UK, Manchester, United Kingdom

^bChemistry Department, Faculty of Science and Arts, Al-Baha University, Al Aqiq, Saudi Arabia

^cSchool of Materials, the University of Manchester, Oxford Road, Manchester, UK, Manchester, United Kingdom

^dSchool of Chemistry, Islamic University, Prince Naif Ibn Abdulaziz Rd, Madinah, Saudi Arabia

NIPHO
Proceedings of International Conference on Perovskite Thin Film Photovoltaics and Perovskite Photonics and Optoelectronics (NIPHO20)

Sevilla, Spain, 2020 February 23rd - 25th

Organizer: Hernán Míguez

Poster, Mousa Hossin, 092
Publication date: 25th November 2019

Abstract:

Alkyl-xanthato bismuth(III) complexes of the form [Bi(S₂COR)₃] where R= Me (1), Et (2), ⁿPr (3), ⁱPr (4), ⁿBu (5), ^sBu (6), ⁱBu (7), Pent (8), ⁱPent (9), ⁿHex (10), ⁿHept (11) and ⁿOct (12) have been prepared and characterised by infrared spectroscopy (IR), nuclear magnetic resonance (¹H and ¹³C) spectra and elemental analysis (EA).¹ Thermogravimetric analysis (TGA) has been applied to study the decomposition temperature for each complex. Then all complexes were used as single-source precursors for the formation of bismuth sulfide (Bi₂S₃) nanocrystals (NCs) at low temperature of 175 °C using melt method.² All synthesised metal sulfides from complexes (1) to (12) were characterised by powder X-ray diffraction (pXRD) and scanning electron microscopy (SEM). The powder X-ray diffraction patterns of Bi₂S₃ (NCs), which is indexed to orthorhombic lattice of bismuthinite revealed that, any change in the xanthate chain length can affect the growth along the (021) peak intensity, Figure 1.³ Despite the low temperature synthesis conditions, the Bi₂S₃ NCs exhibited good crystallinity in keeping with previous uses of metal xanthates complexes.

Figure 1: Powder XRD patterns of Bi₂S₃ NCs obtained [Bi(S₂COR)₃] where R= Me (1), Et (2), ⁿPr (3), ⁱPr (4), ⁿBu (5), ^sBu (6), ⁱBu (7), Pent (8), ⁱPent (9), ⁿHex (10), ⁿHept (11) and ⁿOct (12) precursors at 175 ^oC using melt method.

References:

[1] S. A. Alderhami, D. Collison, D. J. Lewis, P. D. McNaughter, P. O’Brien, B. F. Spencer, I. Vitorica-Yrezabal and G. Whitehead, Dalton Trans., 2019, 48, 15605-15612.

[2] L. Almanqur, I. Vitorica-Yrezabal, G. Whitehead, D. J. Lewis and P. O’Brien, RSC Adv., 2018, 8, 29096-29103.

[3] M. Al-Shakban, P. D. Matthews, G. Deogratias, P. D. McNaughter, J. Raftery, I. Vitorica-Yrezabal, E. B. Mubofu and P. O’Brien, Inorg. Chem., 2017, 56, 9247-9254.

Acknowledgements:

The author would like to acknowledge the Royal Embassy Saudi Arabia Culture Bureau London and Al-Baha University for financial support. A. Al-A. thankful to Ministry of Higher Education in Saudi Arabia for funding and the University of Islamic. M. H would also like to thank Prof Paul O'Brien for all his academic support during in his life and DJL who is funded by EPSRC (grant EP/R020590/1).
