1.1-I1
Bruno Ehrler is leading the Hybrid Solar Cells group at AMOLF in Amsterdam since 2014 and is also a honorary professor at the University of Groningen since 2020. His group focuses on perovskite materials science, both on the fundamental level, and for device applications. He is recipient of an ERC Starting Grant and an NWO Vidi grant, advisory board member of the Dutch Chemistry Council, recipient of the WIN Rising Star award, and senior conference editor for nanoGe.
Before moving to Amsterdam, he was a research fellow in the Optoelectronics Group at Cambridge University following post-doctoral work with Professor Sir Richard Friend. During this period, he worked on quantum dots, doped metal oxides and singlet fission photovoltaics. He obtained his PhD from the University of Cambridge under the supervision of Professor Neil Greenham, studying hybrid solar cells from organic semiconductors and inorganic quantum dots. He received his MSci from the University of London (Queen Mary) studying micro-mechanics in the group of Professor David Dunstan.
2022 Science Board member Netherlands Energy Research Alliance (NERA)
2021 Member steering committee National Growth fund application Duurzame MaterialenNL
2021 Member advisory board Dutch Chemistry Council
2020 Honorary professor Universty of Groningen for new hybrid material systems for solar-cell applications
2020 ERC starting Grant for work on aritifical synapses from halide perovskite
2019 Senior conference editor nanoGe
2018 WIN Rising Star award
2017 NWO Vidi Grant for work on metal halide perovskites
since 2014 Group Leader, Hybrid Solar Cell Group, Institute AMOLF, Amsterdam
2013 – 2014 Trevelyan Research Fellow, Selwyn College, University of Cambridge
2012-2013 Postdoctoral Work, University of Cambridge, Professor Sir Richard Friend
2009-2012 PhD in Physics, University of Cambridge, Professor Neil Greenham
2005 – 2009 Study of physics at RWTH Aachen and University of London, Queen Mary College, MSci University of London
Perovskite solar cells are very efficient, but mobile ions currently hamper their long-term stability. Mobile ions drift and diffuse through the device during operation, driven for example by a light or voltage bias. Since perovskites are intrinsic semiconductors, these ions determine the electric field distribution in a perovskite-based device. However, it is not clear what this means for device operation. I will discuss the influence of the field screening on capacitance and photoluminescence measurements.
The capacitance value measured for a perovskite device depends on the doping level of the perovskite and the adjacent transport layers, and the ion distribution within the perovskite layer. The latter changes with voltage, temperature, and time, so that mobile ions influence all kinds of voltage, temperature, and time-dependent measurements in non-trivial ways. With capacitance measurements, many properties of mobile ions can be accessed, but only if we understand the way the transport layers and doping levels influence these measurements. I will present drift-diffusion simulations that explore this parameter space.
Photoluminescence measurements are also influenced by the local electric field. The presence of a field can lead to drift out of the PL collection zone, or change the local trap filling. Again, mobile ions determine the field, and the local photoluminescence is hence strongly influenced by their presence. I will show lateral device measurements that we use to attempt an understanding of the changes in photoluminescence in the presence of mobile ions.
1.1-I2
Antonio Guerrero is Associate Professor in Applied Physics at the Institute of Advanced Materials (Spain). His background includes synthesis of organic and inorganic materials (PhD in Chemistry). He worked 4 years at Cambridge Dispaly Technology fabricating materiales for organic light emitting diodes and joined University Jaume I in 2010 to lead the fabrication laboratory of electronic devices. His expertise includes chemical and electrical characterization of several types of electronic devices. In the last years he has focused in solar cells, memristors, electrochemical cells and batteries.
Halide perovskite materials are mixed electronic and ionic conductors that find use in several applications. The ionic conductivity is responsible for a memory effect that leads to undesirable hysteresis in the solar cell configuration. Alternatively, a he resistive memory configuration (memristor) this hysteresis is required and needs to be well understood to offer a good control of the conductive states. In this presentation, it is shown how conductive and insulating states are formed via migration of halide vacancy and electrochemically active metals making them useful as memristors. We show that the working mechanism and performance of the memory devices can be tuned and improved by a careful selection of each structural layer. Several configurations are evaluated in which structural layers are modified systematically: formulation of the perovskite,1 the nature of the buffer layer2,3 and the nature of the metal contact4. Overall, we provide solid understanding on the operational mechanism of halide perovskite memristors that has enabled increased stabilities approaching 105 cycles with well separated states of current and further improvements expected.5
1.1-O1

Halide perovskites have been established as one of the most promising semiconductors for a myriad of optoelectronic applications. Besides their exceptional optical properties, perovskites have been demonstrated to behave as mixed ionic-electronic conductors. While ion migration is typically detrimental for conventional perovskite applications (such as solar cells or LEDs), this particular property has proven useful in devices such as memristors, electrochemical transistors, or bolometers. Therefore, it is essential to develop a deep fundamental understanding of the mixed ionic-electronic conduction properties in this class of materials to enable further advances in multiple perovskite-based technologies.
Amongst the vast number of perovskite compositions, Sn-based perovskites have received great attention due to their reduced toxicity and narrow bandgaps compatible with NIR absorption. However, mixed conduction in this class of materials has been underexplored relative to their Pb-based analogues. While a few reports have recently unveiled a smaller degree of ion migration in a limited number of Sn-based compositions, the use of standard electrical characterization techniques to quantify this phenomenon in a wider range of Sn perovskites is still required.
In this work, we used the galvanostatic polarization technique to obtain the ionic and electronic conductivities of various Sn-based perovskite compositions (ASnxPb1-xI3, where A=methylammonium and formamidinium). This technique has been established as one of the most standardized methods to measure the mixed conduction properties of several semiconducting materials. In particular, we shed light on the role of the Sn content (x=0, 0.25, 0.5, 0.75, and 1), the A-site composition, and the concentration of Sn vacancies (tuned by adjusting the content of SnF2 vacancy modulator additive) on the ionic and electronic conductivities. We found ionic conductivity to be intimately correlated to electronic conductivity, suggesting that the electronic carrier concentration is proportional to the number of mobile ions in the perovskite and/or their ionic mobility. These findings provide key design rules to harness ion migration in Sn-based perovskites via compositional engineering.
1.1-O2

Lead halide perovskites are highly promising materials for a wide range of optoelectronic applications, such as photovoltaics and LEDs. However, perovskite optoelectronic devices typically display unwanted, large hysteresis effects under mild operating conditions, which is commonly attributed to the efficient conduction of mobile ions. Here we utilize this efficient ion conduction to make energy-efficient artificial synapses that change their conductive state when a bias voltage is applied. We fabricate low-energy consumption artificial synapses by downscaling of the device in a way that prevents degradation of the perovskite layer during the lithography procedure. The devices demonstrate large resistance changes with energy consumptions in the femtojoule range, among the lowest reported for artificial synapses and comparable to that of biological synapses. Networks of these artificial synapses could potentially emulate the analog and parallel way that information is processed in the brain to achieve orders of magnitude lower energy consumption computation compared to digital computers.
1.2-I1
The replication of neural information processing in electrical devices has been extensively studied over the years. The paradigm of parallel computing, which allows information to be simultaneously detected, processed and stored, is required for numerous applications in many fields. In the case of brain-computer interfaces, another important requirement is the suitability of the device for communication with cells. Organic electrochemical transistors (OECTs) based on PEDOT:PSS are used for this purpose due to their ionic-to-electronic signal transduction and biocompatibility [1]. Many works have demonstrated the reproduction of neural plasticity mechanisms, such as short-term facilitation and long-term potentiation. In each device, the physical mechanism of transduction may be different, but it is known that the electrolyte plays a key role in the functioning of these devices, as it provides the ions responsible for the chemical transmission of information. Focusing on long-term memory, this can be reproduced in the OECTs with the oxidation of the neurotransmitter, as in the case of the biohybrid synapse [2]. It is crucial to understand the influence of the material chemistry and the electrolyte composition on the memory effect of the device, as long-term modulation is based on a change in the ionic balance between the electrolyte and the organic polymer.
This electrolyte-dependency plasticity will be discussed as it should be considered when the OECT is used in a biological environment in which a large number of molecules of a different nature are present in addition to neurotransmitters. Furthermore, I will discuss how conjugated polymers can be engineered with azopolymers (opto-sensitive polymers which switch from cis to trans conformation upon certain light exposure) to feature diverse optoelectronic short and long term plasticity, enabling the use of such platforms as neurohybrid devices as building blocks of retina-inspired devices.
References
1 Bernard et al. (2007). In: Advanced Functional Materials 17.17, pp. 3538–3544.
2 Keene, Scott T et al. (2020). In: Nature Materials 19.9, pp. 969–973
1.2-I2
Juan Carlos Gonzalez-Rosillo obtained holds a M.Sc. in Materials Science and Nanotechnology and a PhD in Materials Science from the University Autonomous of Barcelona. He performed his MSc and PhD research (2011-2017) at the Materials Science Institute of Barcelona (ICMAB-CSIC), where he studied the relation of the resistive switching properties of metallic perovskite oxides with their intrinsic metal-insulator transitions for memristive devices and novel computation paradigms. He also was a visiting researcher at the University of Geneva (CH) and Forschungszentrum Jülich (DE). Then he joined the Massachusetts Institute of Technology (USA) for a postdoctoral position (2017-2020) working on the memristive properties of lithium-based oxides for neuromorphic computing and processing of next-generation solid-state electrolyte thin films for All-Solid-State Batteries and Microbatteries. Juan Carlos has been awarded with a Tecniospring postdoctoral fellowship to join IREC and to develop thin film microbattery architectures to power micro- and nanodevices for the Internet of Things revolution
Title: Unlocking Extra Functionalities: Exploring Energy Storage Materials for Iontronic Applications with Li-Based Materials
Deep learning has demonstrated remarkable success in various applications, but the energy consumption of conventional CMOS circuitry remains a challenge, limiting their implementation to large data centers rather than end-user devices. In response, neuromorphic computing has emerged as a promising solution for highly efficient computation, drawing inspiration from the human brain.
At the core of neuromorphic computing architectures are artificial synapses that mimic the behavior of biological synapses. These synapses must modulate their resistance in an analog manner with minimal energy consumption to adjust synaptic weights. To achieve this, two- and three-terminal devices that utilize ions instead of electrons have been proposed, aiming to reduce energy consumption while improving linearity and symmetry of conductance changes.
Significant progress has been made at the materials level, exploring various ions and material systems, including lithium (Li+), oxygen (O2-), and hydrogen (H+). Li-based materials offer several advantages, such as typically higher diffusivities at room temperature, low-energy intercalation potentials, and a rich library of electrochemically diverse materials already developed for Li-ion batteries. Additionally, the growing industry involving the thin-film processing of Li-based materials for microbattery applications demonstrates the industrial viability of fabricating these materials.
This presentation will provide a historical perspective on the development of Li-based iontronics and highlight recent advancements in two-terminal -memristive or resistive switching devices- and three-terminal -ionic transistors- approaches for electrochemical synapses in neuromorphic computing. This presentation will address as well the challenges faced in this field and discuss future research directions aimed at improving device performance and reliability. The integration of energy storage materials not only enhances the energy efficiency of these architectures but also opens new avenues for their applications in diverse fields, ranging from artificial intelligence to robotics and edge computing in which both their main energy source and the active neuromorphic elements are made with the material class.
1.2-O1

Gaining a deep understanding of the factors governing electrocatalytic reactions requires reliable measurement of the identity and amount of the products generated at the electrode as a function of electrochemical parameters. Detecting these products in real-time enables the observation of otherwise inaccessible, fast and transient phenomena. Coupling mass spectrometry (MS) with electrochemistry (EC) allows for real-time detection with outstanding sensitivity. Several methods have been employed in the monitoring of volatile products: Differential Electrochemical Mass Spectrometry (DEMS) [1] and On-line Electrochemical Mass Spectrometry (OLEMS) [2] have been used successfully to study reaction mechanisms of aqueous systems. Similarly, Online Electrochemical Mass Spectrometry (OEMS) [3] has helped improve our understanding of gas evolution in batteries.
To fully exploit the potential of coupled EC-MS, it is of importance to be able to quantify the amounts of products evolved to accurately relate these amounts to the electrochemical charge passed. To this end, calibration of the MS signals is required. In aqueous systems, MS calibration for some important analytes can be carried out by generating the analyte electrochemically on a catalyst yielding this analyte at close to 100 % faradaic efficiency. Nonetheless, this approach is limited to few analytes, and is especially challenging in non-aqueous systems.
In this contribution, we show how a simple gas-based procedure using chip-based Electrochemistry-Mass Spectrometry (EC-MS) can be used for calibration of electrochemically accessible analytes such as hydrogen and oxygen in aqueous systems. We then demonstrate how we can extend this procedure to analytes not accessible via electrochemical calibration, as well as to non-aqueous electrolytes. We illustrate how quantitative chip-based EC-MS can be used for the identification of surface adsorbates in electrochemical oxidation reactions, and consequently aid in elucidating the role of these species in steering selectivity. [4,5] Finally, we attest the method’s usefulness in non-aqueous systems for studying electrocatalytic reactions such as nitrogen reduction, as well as gas evolution in Li-ion batteries.
1.2-O2
orcid: 0000-0001-7246-2149
The intermittent nature of solar energy is one of the main causes that is delaying the implementation of this renewable energy. In fact, to cover the energy mismatch between production and consumption, it is common for solar cells to be connected to a storage system, mainly batteries. However, having two connected devices is not very practical for portable electronic systems where it is important to keep volume and weight small and require low power consumption. In this context, in recent years research on solar-electrochemical energy storage in a single technology, particularly based on Li-ion batteries, is increasing (LIBs)1, 2.
In this study we present the fabrication of a lithium battery in an adapted coin cell capable of being directly recharged with light energy thanks to the design of a photoelectrode based on a heterostructured Cu2O-TiO2 film3. The electrodeposited Cu2O semiconductor layer is the light harvester component of the photoelectrode, and the TiO2 nanoparticle layer acts as the host of Li+ ions. The semiconductor energy bands and the electrochemical redox potential of the processes involved were determined by UV-vis and UPS spectroscopy and cyclic voltammetry (CV) of the Cu2O and TiO2 films individually. The fabricated half-cell photobattery can be charged in open circuit using only light energy (1 Sun), so that when discharged in darkness at 0.1 C it provides ~150 mAh g-1. The overall system efficiency is 0.29%, calculated as the ratio of output electric energy to input light energy. This value is about an order of magnitude higher than the values reported for the photocharge of lithium-based batteries 1, 4, and is similar to that of zinc-based batteries 5.
